CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426 Page -31-
CLARKE TECHNOLOGY
Encore S2426/L2426
Final Assembly Parts List 11/23/00
Qty Qty
Ref. # Part No. Description “L” “S”
1 10062A Assembly, Recovery Tank 1 1
2 10065A Assembly, Control Panel “L” 1-
10066A Assembly, Control Panel “S” -1
3 30064A Rear Cover 1 1
4 80108A Screw, 10-24 x ½ SS 4 4
5 70080A Plate, Warning 1 1
6 83010A Rivet, Pop
1
/8 22
7 10064A Assembly, Rear Panel “L” 1-
10067A Assembly, Rear Panel “S” -1
8 980651 Washer,
5
/16 Flat 11 11
9 920110 Nut,
5
/16 -18 ESNA 4 4
10 980652 Washer,
5
/16 Lock 7 7
11 85811A Screw,
5
/16 -18 x ¾ 7 7
12 10129A Assembly, Squeegee 32” 1 1
13 10075A Assembly, Squeegee Lift 1 1
14 10069A Assembly, Traverse System “L” 1-
10070A Assembly, Non-Traverse System “S” -1
15 980982 Washer #10 2 2
16 10071A Assembly, Brush Head “L” 1-
10061A Assembly, Brush Head “S” -1
17 81105A Nut,
3
/8-16 ESNA 4 4
18 87031A Washer,
3
/8 Flat SS 4 4
19 50965A Hinge 1 1
20 85395A Screw, ¼-20 x
1
/2 SS 6 6
21 30059A Front Cover 1 1
22 50966A Latch, Front Cover Ref Ref
23 930090 Rivet,
5
/32 x
9
/16 22
24 10063A Assembly, Solution Tank 1 1
25* Page 12 Battery
871334 Battery 12V, 195 AH (wet - UT Post) - 2
871335 Battery 12V, 195 AH (dry - UT Post) - 2
40136A Battery 6V, 250 AH (wet - Stud Post) 4 4
40137A Battery 6V, 250 AH (dry - Stud Post) 4 4
891384 Battery, 6V 330 AH (wet - UT Post) 4 4
891385 Battery, 6V 330 AH (dry - UT Post) 4 4
26 41206A Series Battery Cable (Taper Style) 3 3
41217A Series Battery Cable (Ring Style) 3 3
27 980205 Washer,
5
/16 Fender 4 4
28 85734A Screw,
5
/16-18 x 2 2 2
29 85739A Screw,
5
/16-18 x 3 Hex 2 2
30 87026A Washer, ¼ flat SS 5 5
31 41211A Battery, Cable (Taper Style) 1 1
40174A Battery, Cable (Ring Style) 1 1
32 85518A Screw, ¼-20 x
3
/4 55
NI 10132A Lit Kit 1 1
NI 17531A Pad Driver Assembly 1 -
10140A Pad Driver Assembly - 1
NI 40512A Battery charger 1 1
NI 77092A Label, Gases 1 1
NI 77093A Label, Falling 1 1
NI 70226A Label, Battery 1 1
NI 30070A Accessory Bag 1 1
NI 10072A Parking Brake Assembly "L" 1 -
NI 10073A Parking Brake Assembly "S" - 1
* See page 12 for installation.
