CLARKE TECHNOLOGY Operator's Manual - Encore S2426/L2426 Page -45-
CLARKE TECHNOLOGY
Encore S2426/L2426
Frame Axle Assembly Parts List 11/23/00
Ref. # Part No. Description Qty Qty
1 85700A Screw, ¼-20 x 1 1 -
2 85811A Screw,
5
/16-18 x ¾ 6 6
3 980652 Washer,
5
/16 Lock 6 8
4 980651 Washer, flat
5
/16 66
5 60328A Squeegee Mount Ref Ref
6 60260B Frame Assembly 1 1
7 50968A Caster, Assembly 1 1
8 30071A Wheel Assembly 2 -
69205A Wheel, Non Traverse - 2
9 50967A Transaxle w/mounting hubs 1 -
60266A Non-Traverse Axle Assembly - 1
10 60289A Mount, Transaxle 2 -
11 87031A Washer, flat
3
/8 SS 4 4
12 170883 Washer,
3
/8 Lock 4 4
13 80103A Screw,
3
/8-24 x 1 Hex SS 4 4
14 57423A Ring, Snap Retainer - 2
15 87616A Washer, Nylon - 2
16 980205 Washer,
5
/16 Fender 2 2
17 962620 Screw,
5
/16-24 x ¾ - 2
18 87026A Washer, Flat, ¼ SS 8 -
19 81217A Nut, ¼-20 SS Thin 9 -
20 34711B Wheel Cover 2 2
21 85395A Screw, ¼-20 x ½ SS 2 2
22 980614 Washer, ¼ Starlock 5 2
23 59789A Valve Solution Ref Ref
24 81105A Nut,
3
/8-16 ESNA Ref Ref
25 87031A Washer, Flat
3
/8 SS Ref Ref
26 Ref Solution Tank Ref Ref
27 980205 Washer,
5
/16 Ref Ref
28 85734A Screw,
3
/8-16 x 2 Ref Ref
29 69639A Strap, Static 1 -
30 10135A Hub, Transaxle (includes #9)
31 77267A Label, Tie Down 4 4
32 81108A Nut,
3
/8-24 ESNA 4 4
Traverse
Non-Traverse
