ALZRC DEVIL 380 FAST - Page 34

18-EXPLODED VIEW, TAIL SYSTEM
18-EXPLODED VIEW, HEAD SYSTEM
CHAPTER 18 / EXPLODED VIEW, TAIL SYSTEM PAGE 35
PAGE 34 CHAPTER 18 / EXPLODED VIEW, HEAD SYSTEM
Head System
POS Name Specification Quantity
1 Washer ø 7,5x ø 10x0,5 2
2 Plastic Linkage Ball M2 4
3 Swashplate 01 Aluminum 1
4 Swashplate 02 Aluminum 1
5 Swashplate 03 Aluminum 1
6 Main Spindle Steel 1
7 Main Blade Grip Aluminum 2
8 Main HUB Aluminum 1
9 Swashplate Arm Aluminum 2
10 Main Blade Grip Arm Aluminum 2
11 Damper Plastic 2
12 Linkage Servos Plastic 3
13 Radius Plastic Arm Plastic 2
14 Uniball M2 Female Aluminum 1
15 Uniball M2 Male Steel 11
16 Linkage M2x22mm 2
17 Button Head Cap Screw M2x5mm 15
Head System
POS Name Specification Quantity
18 Socket Head Cap Screws M2 x 8mm 2
19 Socket Head Cap Screws M2 x 10mm 4
20 Socket Head Cap Screws M2.5 x 8mm 2
21 Head Cap Screws Shoulder M3 x 16mm 1
22 Head Cap Screws Shoulder M3 x 18mm 2
23 Button Head Cap Screw M4 x 6mm 2
24 Washers ø 2.1x ø 5 x 0.5 2
25 Washers ø 2.2x ø 4x0.3 3
26 Metric Hex Nylon Nuts M3 3
27 Bearing ø 5x ø 10x4 4
28 Thrust Bearing ø 5x ø 10x4 2
29 Oring DI=6,75, S=1,78 2
30 Flanged Bearing ø 2x ø 5x2.5 8
31 Rad Bearing ø 25x ø 32x4 1
32 Spherical Bearing ø 12x ø 22x7 1
33 DS215MG V3 Servo 3
