Symptom Possible Causes Corrective Action
Defrost thermostat faulty Check defrost thermostat. Replace if
defective.
Evaporator fan faulty Check fan motor. Replace if
defective.
Defrost heater remains open Check defrost heater continuity.
Replace if faulty.
Defrost control faulty Check control and replace if
defective.
Open wire or connector Check wiring and connections.
Repair as necessary.
Frost or ice on evaporator
Refrigerant shortage or restriction Check for leak or restriction. Repair,
evacuate and recharge system.
Loose wire or thermostat
connections
Check wiring and connections.
Repair as necessary.
Supply voltage out of specification Check input voltage. Correct any
supply problems.
Overload protector open Check overload protector for
continuity. If open, replace overload.
Note:
Ensure
overload/compressor are below
trip temperature before testing.
Faulty compressor motor capacitor Check capacitor for open/short.
Replace if necessary.
Note: Discharge capacitor before
testing.
Faulty fan motor Check fan motor. Replace if
defective.
Restricted air flow Check condenser and grille for dirt.
Clean.
Unit starts and stops frequently
(cycles on and off)
Refrigerant shortage or restriction Check for leak or restriction. Repair,
evacuate and recharge system.
Troubleshooting Chart
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitor through a 10,000 ohm resistor before attempting to service, unless test procedures require power to be
connected. Ensure all ground wires are connected before certifying unit as repaired and/or operational.
WARNING
