Amana SRD25S3 User Manual

RS1300003 Rev. 0 76 December 1997
Kit Instructions
Side-by-Side Refrigerator
HGK300 Black Handle and
Toe Grille Kit
Installation Instructions
Introduction
RECOGNIZE THIS SYMBOL AS A
SAFETY PRECAUTION
Caution
To avoid personal injury and property damage, observe
all safety instructions.
Read entire manual before installing kit. Confirm all
parts listed are included in kit. If parts are missing,
contact source from whom kit was purchased.
Important:
• Mechanical experience is required to install trim kit.
• If unable to solve a problem during installation,
contact source from whom kit was purchased.
Description Qty
Toe Grille
1
Top Trim, Freezer Door
1
Center Trim, Freezer Door (Dispenser Models)
1
Bottom Trim, Freezer Door
1
Top Trim, Refrigerator Door
1
Center Trim, Refrigerator and Freezer Door
2
Bottom Trim, Refrigerator Door
1
Door Handle
2
Black Handle Insert
2
Black Handle Insert
2
Door Stop
2
Toe Grille Clip
2
Installation Instructions
1
Parts List
Procedure
Caution
To avoid property damage, protect soft vinyl or other
flooring with cardboard, rugs, or other protective
material.
Caution
To avoid personal injury, protect hands and arms. Trim
pieces may have sharp edges.
Important: Save all screws and reuse in original
location.
1. Remove upper and lower handle trim from both
doors by grasping trim along inside edge of door
and pulling forward. Remove inserts above and
below each handle.
2. Remove door handles by removing screws.
