RS1300003 Rev. 0 82 December 1997
Kit Instructions
Introduction
RECOGNIZE THIS SYMBOL AS A
SAFETY PRECAUTION
Caution
To avoid personal injury and property damage, observe
all safety instructions.
WARNING
To avoid electrical shock which can cause severe
personal injury or death, disconnect power to
refrigerator before installing kit. After installing kit,
reconnect power.
Caution
To avoid property damage, protect soft vinyl or other
flooring with cardboard, rugs, or other protective
material.
Caution
To avoid personal injury, protect hands and arms. Trim
pieces may have sharp edges.
Read entire manual before installing kit. Confirm all parts
listed are included in kit. If parts are missing, contact
source from whom kit was purchased.
Important
• Mechanical experience is required to install trim kit.
• Depending on installer’s knowledge and skill,
installation can take from one to three hours.
• Transfer food to an alternate cooling source. Check
refrigerator warranty certificate for specific
coverage. Warranty does not cover food loss.
• Ensure trim pieces adhere properly by confirming
surfaces are clean, dry and free of adhesive
residue.
• If unable to solve a problem during installation,
contact source from whom kit was purchased.
Side-by-Side Refrigerator
DS19, DS20 and DS21 1/16"
Trim Kits with 1/4"
Retainers
Installation Instructions
Decorator Panel Dimensions
Listed below are required height x width dimensions for
decorator panels. Panels are not supplied with this kit
and can be purchased locally.
Caution
To avoid personal injury or property damage,
refrigerator panels should not weigh more than 30
pounds (14 kilograms) and freezer panels should not
weigh more than 15 pounds (7 kilograms).
21 cubic foot 1/16" (2 mm)
Panel Dimensions
Without Dispenser
Refrigerator Door 61 7/8" x 15 13/16"
(1572 mm x 402 mm)
Freezer Door 61 7/8" x 13 15/16"
(1572 mm x 354 mm)
With Dispenser
Refrigerator Door 61 7/8" x 15 13/16"
(1572 mm x 402 mm)
Upper Freezer Door 17 9/16" x 13 15/16"
(446 mm x 354 mm)
Lower Freezer Door 32 3/16" x 13 15/16"
(818 mm x 354 mm)
21 cubic foot 1/4" (6 mm)
Panel Dimensions
Without Dispenser
Refrigerator Door 61 1/4" x 15 3/16"
(1556 mm x 386 mm)
Freezer Door 61 1/4" x 13 5/16"
(1556 mm x 338 mm)
With Dispenser
Refrigerator Door 61 1/4" x 15 3/16"
(1556 mm x 386 mm)
Upper Freezer Door 16 7/8" x 13 5/16"
(429 mm x 338 mm)
Lower Freezer Door 31 3/8" x 13 5/16"
(797 mm x 338 mm)
27 cubic foot 1/16" (2 mm)
Panel Dimensions
Non Electronic
Refrigerator Door 61 7/8" x 19 9/16"
(1572 mm x 497 mm)
Upper Freezer Door 17 9/16" x 13 15/16"
(446 mm x 354 mm)
Lower Freezer Door 32 3/16" x 13 15/16"
(818 mm x 354 mm)
Electronic
Refrigerator Door 61 7/8" x 17 3/4"
(1572 mm x 451 mm)
Upper Freezer Door 17 9/16" x 13 15/16"
(446 mm x 354 mm)
Lower Freezer Door 32 3/16" x 13 15/16"
To Next Page
