December 1997 79 RS1300003 Rev. 0
Kit Instructions
Parts List
Item Description Qty Length
DS18E
Black
DS18L
Almond
DS18S
Satin
DS18W
White
DS22E
Black
DS22S
Satin
1 Side Trim, Refrigerator
and Freezer Door
2 X X X X X X
2
Bottom Trim,
Refrigerator Door
1 X X X X X X
3
Bottom Trim,
Freezer Door
1 X X X X X X
4
Top Trim,
Refrigerator Door
1 X X X X X X
5 Top Trim, Freezer Door 1 X X X X X X
6
Top Trim, Dispenser
1 13 7/8" X X X X X X
7
Bottom Trim, Dispenser
1 13 9/16" X X X X X X
8
Panel Trim, Refrigerator
and Freezer Door
2 61 29/32" X X X X X X
9
Panel Trim, Lower Ice
and Water Freezer
Door
1 32 1/8" X X X X X X
10
Panel Trim, Upper Ice
and Water Freezer
Door
1 17 7/32" X X X X X X
11
Screw, Bottom Trim
5 X X X X X X
12
Spacer, Refrigerator
Door Bottom Trim
1 X X X X X X
13
Spacer, Freezer Door
Bottom Trim
1 X X X X X X
14
Installation Instructions
1 X X X X X X
Procedure
Caution
To avoid personal injury or property damage, two
people should remove and rehang each door.
Caution
To avoid personal injury or property damage,
temporarily tape doors shut.
Important
Save all screws and reuse in original location.
1. Tape doors shut using masking tape.
WARNING
To avoid electrical shock which can cause severe
personal injury or death, green ground wire must
remain attached to hinge.
2. Remove top hinge covers by removing screws.
Trace around top hinges with a pencil. This helps
alignment when reassembling. On dispenser
models, unplug top hinge wire connectors. Remove
top hinge screws.
3. Remove tape from refrigerator door. Grasp
refrigerator door securely and lift up while opening.
This will free door from bottom hinge pin. Top hinge
may come off door.
4. Remove toe grille by pulling forward.
Caution
To avoid property damage, drain water from water tube
into small bucket.
5. Dispenser Models
Loosen water tube clamp screw. Loosen plastic
water tube union nut. Gently pull water tube away
from union nut and through tube clamp.
To Next Page
