RS1300003 Rev. 0 56 December 1997
Water Flow
Water Temperature Chart (Approximate)
0
10
20
30
40
50
60
70
12345
Number of 8-ounce Glasses of Water
Water temperature has stabilized for at least 12 hours in water reservoir
Fresh food compartment temperature is 38–40 degrees Fahrenheit
Temperature in Fahrenheit
90o Ambient
Normalized 39o
64o Ambient
Normalized 39o
“S” Model Side x Side
Ice & Water Dispenser
Water Flow Diagram
Dispenser Water Temperature Chart
SOLENOID
VALVE
(DOUBLE)
1/4" O.D.
PLASTIC
TUBING
ICE & WATER
DISPENSER
To Next Page
