Amana SRD25S3 User Manual

December 1997 31 RS1300003 Rev. 0
Electronic Functional Description
To avoid electrical shock which can cause severe personal injury or death, disconnect power to
refrigerator using power switch before servicing. Wires removed during disassembly must be replaced
on proper terminals to insure correct grounding and polarization. After servicing, reconnect power using
power switch.
WARNING
100-298-03 REF-AMP-03 SN. 2307 10627301
9309
E3
K1
Ground
Line Volta
g
e (L1)
Neutral (L2)
Freezer Door Open
Refri
g
erator Door
Open
Defrost Heater
Defrost Heater Rela
y
Defrost Terminator
Comp./Cond. Fan
Power Switch
Comp./Cond. Fan Rela
y
Evaporator Fan
Evaporator Fan Rela
y
Fresh Food Fan
12 Pin Connector
Capacitor
Transformer
