December 1997 91 RS1300003 Rev. 0
Kit Instructions
Side-by-Side Refrigerator
1/4" (6 mm) Trim and Handle
Conversion Kit
Installation
Instructions
Introduction
RECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION
Caution
To avoid personal injury and property damage,
observe all safety instructions.
Read entire manual before installing kit. Confirm all
parts listed are included in kit. If parts are missing,
contact source from whom kit was purchased.
Important
• Mechanical experience is required to install trim
kit.
• Depending on installer’s knowledge and skill,
installation can take from one to three hours.
• Ensure trim pieces adhere properly by confirming
surfaces are clean, dry and free of adhesive
residue.
• If unable to solve a problem during
installation, contact source from whom kit was
purchased.
Decorator Panel Dimensions
Listed below are required decorator panel sizes.
Panels are not supplied with this kit and can be
purchased locally.
Caution
To avoid personal injury or property damage,
refrigerator panels should not weigh more than 30
pounds (14 kilograms) and freezer panels should
not weigh more than 15 pounds (7 kilograms).
Without Dispenser
Refrigerator Door 63 3/32" x 19 3/8"
(1603 mm x 492 mm)
Freezer Door 63 3/32" x 13 3/4"
(1603 mm x 349 mm)
With Dispenser
Refrigerator Door 63 3/32" x 19 3/8"
(1603 mm x 492 mm)
Upper Freezer Door 18 3/8" x 13 3/4"
(466 mm x 349 mm)
Lower Freezer Door 31 13/16" x 13 3/4"
(808 mm x 349 mm)
To Next Page
