Table 3
Insert two AAA batteries.
After inserting the batteries, the remote sensor LED indicator will light for 4 seconds, and then
flash once per 60 seconds thereafter. Each time it flashes, the sensor is transmitting data.
Verify the correct channel number (CH) and temperature units of measure (°F vs. °C) are on the
display, as shown in Figure 39.
Figure 39
(1) temperature
(2) temperature units (°F vs. °C)
(3) channel number
Close the battery door. Make sure the gasket (around the battery compartment) is properly seated
in its trace prior to closing the door. Tighten the set screw.
6.5.2 Probed Thermometer Installation
