Ambient Weather WS-100 User Manual

Version 1.0 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 6
QTY
Item
1
Anemometer Mounting Bracket Back
Plate (pole mount)
Dimensions: 3 x 3 x 1”
4
Pole mounting nuts (M5) / bolts (∅5)
4
Tapping screws
2
Pole mounting nuts (M3) / bolts (∅3)
Figure 4
4.3 Rain Gauge (optional)
QTY
Item
1
WS-12-RAIN
Rain Gauge
Dimensions: 8 1/4" x 7 3/4" x 5" (5"
diameter)
1
Rain Gauge Filter
Dimensions: 2.48 x 2.48 x 1.1in
2
Pole mounting U-bolt / nuts (M5)
Figure 5
If sold separate from the anemometer (only one pole assembly is required per system), the following parts
are included:
