Ambit PIB v1.5 - Page 15

Section 1 • Introduction
11
Figure1-1
Basalowrateonly(PCAmode)infusionpattern
ForFigure1-1,thebasalowrateis10ml/hr.Themaximumavailablebasalowrateis20ml.
Figure1-2
Bolusonly(PCAmode)infusionpattern
The settings for Figure 1-2 are a bolus volume of 10 ml and a lockout time of 30 minutes. After
a bolus is requested and delivered, a lockout time begins. A bolus is delivered only when the
BOLUS button or remote BOLUS switch is pressed. During the lockout time, the pump will
beep when a bolus is requested, but no bolus will be delivered.
CAUTION: Right after programming the pump or clearing history, a bolus will be delivered
if requested. The pump assumes that clearing history or programming/
reprogramming a new therapy is starting.
Basal
165
Time (Minutes)
180
195
210
235
240
0
150
135
Flowrate (ml/hr)
75
90
105
120
0
15
30
45
60
10
