Figure1-7
Doseandbolus(P+Pmode)infusionpatternofmultipleboluses
(Figure1-7onlyappliestothePIB-IL v1.5pump)
As shown in Figure 1-7, the total volume infused during the interval is reset to zero at the
beginning of each interval. As each bolus and dose is delivered, the total volume infused during
the interval is increased (see bold line). If the volume infused during the interval reaches the
interval limit (See Figure 1-8) or bolus delivery would overlap the end of a dose interval (See
Figure 1-7), then the bolus is stopped immediately.
NOTE: The undelivered portion of the bolus will not be delivered later.
