Introduction
Page 1-4
Accelerated Graphics Port (AGP)
The AGP slot on the board is compliant with the new AGP 3.0 specification. This
new specification enhances the functionality of the original AGP specification by
allowing 8X data transfers ( 8 data samples per clock) resulting in maximum band-
width of 2.1GB/s. In addition, it defines 1.5 volt power supply operation. Complying
with this specification, this board supports external AGP-8X/4X cards with Fast
Write Transactions. Only 1.5V AGP cards are supported.
Ultra ATA/66/100/133
The MCP provides two independent ATA133 IDE controllers, supporting standard
programmable input/output (PIO) and Direct Memory Access (DMA) mode
operations, as well as UltraDMA-133/100/66/33 standards for a maximum data
transfer rate of 133MBps per channel.
LAN (Optional)
The motherboard mounts the LAN chipset. It allows the mainboard to connect to a
local area network by means of a network hub.
Hardware Monitoring
Hardware monitoring allows you to monitor various aspects of your system
operations and status. The features include CPU temperature, voltage and RPM of
fan.
IEEE1394 (Optional)
IEEE 1394 is a high-speed serial bus developed by Apple Instruments that allows
users to connect up to 63 devices to the serial bus on a PC. IEEE is sometimes called
the IEEE 1394 standard, the i.Link connector, FireWire, and the High Performance
Serial Bus (HPSB).

AMD Athlon Specifications

General

Microarchitecture	K7
Architecture	x86
Manufacturer	AMD
Core Count	1
Thread Count	1
Socket	Socket A
Manufacturing Process	180 nm
L1 Cache	128 KB (64 KB Instruction + 64 KB Data)
L2 Cache	64 KB to 512 KB
Clock Rate	500 MHz
FSB	100 MHz
