Page 2-1
Section 2
FEATURES
Mainboard Features
Processor

Supports 462-pin SocketA for AMD Athlon XP and Barton processors
with 266/333/400MHz Front Side Bus
- Athlon XP (1500+ to 2800+) with 266/333MHz Front Side Bus,
- Barton (2500+ to 3000+) with 333/400MHz Front Side Bus
Chipset

nVidia AGPset : nForce2 Ultra 400 (nForce2 SPP) + MCP
Main Memory

Three 184-pin DDR DIMM sockets for 64-bit, Unbuffered, Single/
Double-side and Non-ECC DDR-200/266/333/400 DIMMs

Supports 128-bit dual channel memory architecture

Supports up to 3GB memory size
BIOS

Flash EEPROM with Award BIOS
- ACPI v2.0 compliant
- S3 (Suspend to DRAM) sleep-state support
- SMBIOS (System Management BIOS)

v2.2 compliant
- Supports Power failure recovery
- Capable to waked the computer up from specific states by LAN, Power
switch, PME#, RTC alarm, USB, PS2 KB&Mouse, Modem ring on COM#1
Onboard PCI Devices
 1394 --> Embedded Agere FW323 1394 controller with 3 ports
solution
- IEEE-1394a compliant with up to 400Mbps bandwidth
(Optional)
