Page 2-2
 LAN --> Embedded 10/100Mbps Fast Ethernet controller with
RTL8201BL PHY
Embedded 10/100Mbps Fast Ethernet controller with
RTL8101L chip (for high-level model only)
 S-ATA --> Embedded Serial ATA controller with Silicom Image SIL3112A)
for 2 ports solution, up to 1.5Gbs transfer rate
 IDE --> Embedded IDE controller supports 2 IDE ports for up to 4
IDE devices
- Supports ATA-133 with up to 133Mbps bandwidth
Legacy IO Controller
 Winbond W83627HF LPC IO controller with floppy, printer, game,
serial and CIR/SIR interface
Audio
 Six channel audio with analog and digital output using CMI9739A AC97
CODEC
- AC97 v2.2 compliant
- In 2-CH mode, supports Line-In (Blue), Line-Out (Green) and Mic-In
(Pink) at rear panel
- In 6-CH mode, supports Rear out (Blue), Front out (Green) and
Center&Subwoofer (Pink) at rear panel
- Supports CD-In, Aux-In and S/PDIF-In/Out interface
- Supports Line-out and Mic-In for front panel
Peripheral Interfaces
 PS/2 keyboard and mouse ports (at rear panel)
 One Parallel (printer) port (at rear panel)
 Two RJ45 LAN connector (at rear panel)(Optional)
 Six USB2.0 ports (4 at rear panel)
 One game port
 Two Serial ports
(Optional)
(Optional)

AMD Athlon Specifications

General

Microarchitecture	K7
Architecture	x86
Manufacturer	AMD
Core Count	1
Thread Count	1
Socket	Socket A
Manufacturing Process	180 nm
L1 Cache	128 KB (64 KB Instruction + 64 KB Data)
L2 Cache	64 KB to 512 KB
Clock Rate	500 MHz
FSB	100 MHz
