Page 2-3
 One floppy drive interface
 Two IDE interfaces
 Three 1394 interfaces (Optional)
 Two S-ATA interfaces (Optional)
 Three Fan connectors
Front Panel Controller
 Supports Reset & Soft-Off switches
 Supports HDD & Power LEDs
 Supports PC speaker
Expansion Slots
 One AGP slots supporting 1.5v 4X/8X AGP cards
- AGP v3.0 compliant
 Five PCI bus sockets

with Bus Master support
- PCI v2.2 compliant
Other Features
 Magic Health  a H/W monitoring software utility, for voltages, tempera-
tures and fan-speeds sensing
 EZ Boot  An easy way let end-user can choose to boot from hard drive,
CD-ROM, floppy, 
 Excellent Over clocking capabilities by
- subtle voltage tuning on CPU, Memory, AGP
- subtle frequency tuning on FSB

Supports complete FSB/Memory and FSB/AGP Asynchronous scheme for
over-clocking
 P80P for system debugging
 CPU Overheating Protection
Form Factor
 305 x 245 mm ATX size

AMD Athlon Specifications

General

Microarchitecture	K7
Architecture	x86
Manufacturer	AMD
Core Count	1
Thread Count	1
Socket	Socket A
Manufacturing Process	180 nm
L1 Cache	128 KB (64 KB Instruction + 64 KB Data)
L2 Cache	64 KB to 512 KB
Clock Rate	500 MHz
FSB	100 MHz
