INSTALLATIONS

Jumper Locations on MB500

Jumpers on MB500 ............................................................................... Page

JP2: Voltage Setting for LVDS .................................................................. 9

JP6: Clear CMOS Contents ........................................................................ 9

JP3, JP4, JP5: RS232/422/485 (COM2) Selection ...................................... 9

JP7: Case Open Setting ............................................................................. 10

JP8: CompactFlash Master/Slave Selection .............................................. 10

JP9: ATX/AT Mode Select ...................................................................... 11

MB500 User’s Manual
