INSTALLATIONS

MB500 User’s Manual 11

Connectors on MB500

The connectors on MB500 allows you to connect external devices such

as keyboard, floppy disk drives, hard disk drives, printers, etc. The

following table lists the connectors on MB500 and their respective

functions.

Connector Locations on MB500 .................................................. 12

CN1: DC Jack (DC in, 12V only) ................................................ 13

CN2: PS/2 Keyboard and Mouse Connectors .............................. 13

CN3: COM1 Serial Port ............................................................... 13

CN4: Parallel Port Connector ....................................................... 14

CN5: VGA CRT connector .......................................................... 14

CN6: 10/100 RJ45 Connector (for MB500F only) ....................... 15

CN7: 10/100 RJ45 and USB Connectors ..................................... 15

CN8: Line Out, Line In, Mic Connector ...................................... 15

CN9: Compact Flash Socket ........................................................ 15

PCI1: PCI Slot .............................................................................. 15

DDR1: 184-pin DDR DIMM Socket ........................................... 15

J2: ATX Power Supply Connector ............................................... 16

J3: LVDS Connector .................................................................... 16

J4: LCD Inverter Connector ......................................................... 17

J5: LCD (TTL) Connector ............................................................ 17

J6, J7, J8: COM2, COM3, COM4 Serial Ports............................. 18

J9: IrDA Connector ...................................................................... 18

J10: Digital 4-in 4-out I/O Connector .......................................... 19

J11: Mini PCI Socket ................................................................... 19

J12: For Right Speaker ................................................................. 19

J13: Wake On LAN Connector .................................................... 19

J14: For Left Speaker ................................................................... 19

J15: USB Connector (USB2/USB3) ............................................. 19

J16: Front I/O Connector .............................................................. 20

J17: Function Connector .............................................................. 20

J18: CD-In Audio Connector ....................................................... 20

FDD1: Floppy Drive Connector ................................................... 20

IDE1: Primary IDE Connector ..................................................... 21

FAN1, FAN2: Fan Power Connectors ......................................... 21
