4-12 | 3050-SLR Moisture Analyzer
Figure 4-9.
Status tab.
Figure 4-10.
Monitor tab.
Status Tab
Use the Status tab to view current readings and the status of the analyzer.
Monitor Tab
Use the Monitor tab to check on analyzer operation. From this tab you can also calibrate
the internal low meter and test the alarm contacts and mA output of the analyzer.
Using the test buttons takes the analyzer ofline.

NOTE
