4-22 | Model 900 ADA / Model 930 Sulfur Pit Analyzers
RUN / CFG Mode – F3 Commands
Keystroke Term Denition
F3 • TrendType This denes which concentration addition will be displayed on the Trend output (see
F6 3 8). TrendType is the sum of two concentrations (for example, 3 = [SO
2
] + [H
2
S]):
1 = [SO
2
] 8 = [CS
2
] {if measuring}
2 = [H
2
S] 16 = [Sv]
4 = [COS] {if measuring} 32 = [NDr]
F3 – — —
F3 0 Compenz ** The operational status of each compensation function, where ‘z’ = 1..4.
1 = NDR 0,2 = disabled (O󰀨)
2 = Sv 1 = passive\static
3 = COS {if measuring} 3 = active\dynamic
4 = CS
2
{if measuring}
F3 y My\z **The value in each row (’y’ = 1..6) and column (‘z’ = 1..6) in the calculation matrix.
y = F3 1..F3 6 (row) z = 1..6 (column)
F3 1 = M1 M1\1..6
F3 2 = M2 M2\1..6
F3 3 = M3 M3\1..6
F3 4 = M4 M4\1..6
F3 5 = M5 M5\1..6
F3 6 = M6 M6\1..6
F3 7 CVect1\z **The vectors for the rst compensation calculations, where ‘z’ = 1..8 or 1..9.
1 = CVect1\1
2 = CVect1\2
3 = CVect1\3
4 = CVect1\4
5 = CVect1\5
6 = CVect1\6
7 = CVect1\7
8 = CVect1\8
9 = CVect1\9 (applications with COS/CS
2
Software version only)
F3 8 CVect2\z **The vectors for the second compensation calculations, where ‘z’ = 1..2(..4)
1 = CVect2\1
2 = CVect2\2
3 = CVect2\3 (applications with COS/CS
2
Software version only)
4 = CVect2\4 (applications with COS/CS
2
Software version only)
F3 9 AvgTz **The averaging times (seconds) of the compensation functions, where ‘z’ = 1..4.
1 = AvgT1
2 = AvgT2
3 = AvgT3
4 = AvgT4
