Ametek BARBEN ANALYTICAL OXY visor

9
IOM (Safety) - Installation, Operation and Maintenance
Optical Oxygen Analyzer
2.7 Hazardous Area Agency Cercaon & Markings - [Recapitulaon]
2.7.1 Zone 1 Group IIC with Specic Condions of Use
2.7.2 Zone 2 Group IIC with Specic Condions of Use
OXYvisor is certied as Process Control Equipment for use in Zone Classied Hazardous Locations (QVAJ and QVAJ7) - Zone 1, Group IIC
Specic Conditions of Use - Consult Drawing No. 2P0345 for complete installation details.
• Unused entries shall be closed with suitable certied Ex db blanking elements with a minimum IP66 rating
• Flameproof joints are not intended to be repaired. For repair or replacement of any part, contact Barben Analytical.
0539
II 2 G Ex db op is IIC T4 Gb
Ex db op is IIC T4 Gb
Ta = -20 C to +55 C
Ta = -20 C to +55 C
Ta = -20 C to +55 C
Ta = -20 C to +55 C
Class 1 Zone 1 AEx db op is IIC T4 Gb
Ex db op is IIC T4 Gb
Certicate Number: DEMKO 19 ATEX 2031, issued by UL DEMKO International A/S
Certicate Number: IECEx UL 19.0040 issued by UL LLC
ATEX Zone 1, Group IIC Markings:
IECEx Zone 1, Group IIC Markings:
North American Zone 1, Group IIC Markings:
Standards: EN 60079-0:2012+A11:2013
EN 60079-1:2014
EN 60079-28:2015
Standards: IEC 60079-0, 6th Edition, Issued 2011-06
IEC 60079-1, 7th Edition, Issued 2014-06
IEC 60079-28, 2nd Edition, Issued 2015-05
US NEC Standards: UL 60079-0, 6
th
Edition, Dated 2013-07-26
UL 60079-1, 7
th
Edition, Dated 2015-09-18
UL 60079-28, 2
nd
Edition, Dated 2017-09-15
CAN CEC Standards: CSA C22.2 No. 60079-0, 3rd Edition, Dated 2015-10
CSA C22.2 No. 60079-1, 3rd Edition, Dated 2016-05
CSA C22.2 No. 60079-28, 1st Edition, Dated 2016-12
2.8 Product Label / Name Plate
2.8.1 - Product Label / Name Plate Overview
2.7.3 Class I, Division 2 Groups A,B,C, & D
The Product Label (Name Plate) is found at the top of the analyzer (Figure 1). The product label identies important information and attributes of the
specic model and should be reviewed in detail prior to installation.
Class I, Division 2, Groups A, B, C, & D T4A
US NEC Standards: UL 12.12.01 - Edition 9 Issued 2017/09/15
CAN CEC Standards: CSA C22.2 No. 213-17 - Edition 3 Issued 2017/09/15
The OXYvisor is certied as Process Control Equipment for use in hazardous locations (QUZW, QUZW7) Class I, Division 2 Groups A, B, C, & D
!
WARNING
!
WARNING
Section 2
Technical Product Specication
The OXYvisor is certied as Process Control Equipment for use in Zone Classied Hazardous Locations - Zone 2, Group IIC
Specic Conditions of Use - Consult Drawing No. 2P0346 for complete installation details.
• Transient protection shall be provided that is set at a level not exceeding 140% of the peak rated voltage value at the supply terminals to the equipment.
• The equipment shall only be used in an area of not more than Pollution Degree 2, as dened in IEC/EN 60664-1.
II 3 G Ex ec [ic] op is IIC T4 Gc
Ta = -20 C to +55 C
Certicate Number: DEMKO 19 ATEX 2036
ATEX Zone 2 Markings:
Standards: CENELEC EN 60079-0 +A11 2012, 2013
CENELEC EN 60079-7 +A1 2015, 2018
CENELEC EN 60079-11 2012
CENELEC EN 60079-28 2015
Ex ec [ic] op is IIC T4 Gc
Class 1 Zone 2 AEx ec [ic] op is IIC T4 Gc
Class 1 Zone 2 Ex ec [ic] op is IIC T4 Gc
Certicate Number: IECEx UL 19.0072
North American Zone 2, Group IIC Markings:
Standards: IEC 60079-0, Edition 6, Issued 2014-10
IEC 60079-7, Edition 5.1, Issued 2014-06
IEC 60079-11, Edition 6, Issued 2014-10
IEC 60079-28, Edition 2, Issued 2015-05
IEC 61010-2-201 Edition 1, Issued 2013
US NEC Standards: UL 60079-0, Edition 6, Dated 2017/10/20
UL 60079-7, Edition 5.1, Dated 2017/04/21
UL 60079-11, Edition 6, Dated 2014/03/28
UL 60079-28, Edition 2, Dated 2017/12/08
CAN CEC Standards: CSA C22.2 No. 60079-0, Edition 3, Issue Date 2015/10/01
CSA C22.2 No. 60079-7, Edition 2, Issue Date 2016
CSA C22.2 No. 60079-11, Edition 2, Issue Date 2014/02/01
CSA C22.2 No. 60079-28, Edition 1, Issue Date 2016
