IOM (Safety) - Installation, Operation and Maintenance
Optical Oxygen Analyzer
The OXY visor measures from trace level (ppmv(g) / ppb(aq)) oxygen to percent level oxygen in both the gas and liquid phases. It’s intended for
indoor and outdoor use, as a continuous analytical measuring device, in manufacturing and industrial processes, along with laboratories.
The analyzer is either pipe or wall mounted in the proximity of the measuring point. The analyzer has a local display and can be operated (conguration,
calibration, etc.) with the HMI via the “through-the-glass,” keypad or via the
OXYvisor software on a PC. The analyzer connects to a ber optic
cable, via a ber optic SMA connection located in the easily accessible junction box. The ber optic cable links the analyzer to the process sensor,
which is mounted directly into the process or within an extractive sample system. The analyzer is fully compatible with all of the Barben Optical Sensors
(BOSx) which are sold separately or included with integrated Sample Calibration Panels (SCP).
The purpose of this abridged manual is to specically inform the user of all the pertinent and required information, as it pertains to safety to install and
operate this product. The product is to be used for its intended purposes, as detailed below in Section 1.2, and by qualied personnel.
For additional product and services related to the use and installation of this OXY visor product, such as technical assistance, eld start-up services,
classroom product trainings, wet-gas sample probes, heated sample lines, pressure reduction stations or other needs please contact us at Barben
Analytical or a factory qualied local representative (see back page for complete contact information).
Section 1 - General Information & Safety
1.1 Introducon - Purpose of this Manual
1�2 About the OXYvisor Product - (Overview)
Denition of the symbols for hazardous, cautionary, precautionary and general information are found and dened here.
1.3 Denion of Symbols
WARNING
Safety warning indicates a potentially or imminently hazardous situation which, if not avoided,
may result in personal injury or environmental contamination.
!
WARNING
!
WARNING
AVERTISSEMENT
L’avertissement de sécurité indique une situation potentiellement dangereuse ou imminente qui, si elle
n’est pas évitée, peut entraîner des blessures ou une contamination de l’environnement.
!
WARNING
!
WARNING
CAUTION
General warning, caution, that if an operating procedure which, if not strictly observed, may
result in damage or malfunction of the analyzer.
!
CAUTION
!
CAUTION
ATTENTION
Avertissement général, mise en garde, si une procédure d’exploitation qui, si elle n’est pas
strictement observée, peut entraîner des dommages ou un dysfonctionnement de l’analyseur.
!
CAUTION
!
CAUTION
CAUTION
Caution, possibility of electric shock may occur if an operating procedure which, if not strictly
observed, may occur.
ATTENTION
Attention, un choc électrique peut se produire si une procédure qui, si elle n’est pas strictement
observée, peut se produire.
IEC 60417-5019
Protective conductor terminal. (Borne du conducteur de protection.)
IEC 60417-5032
Alternating Current (AC) (Courant alternatif)
IEC 60417-5031
Direct Current (DC) (Courant continu)
Useful and/or important information that should not be overlooked (Informations utiles et / ou
importantes à ne pas négliger)
USEFUL INFORMATION
USEFUL INFORMATION
IEC 60417-5020
Frame or chassis terminal. (Terminal cadre ou châssis )
Section 1
General Info & Safety
