4. Low Current Shutdown
If the charger output falls below a predetermined
level, a low current shutdown will occur. All 4
LEDS will be flashing and the display will read ―Low
Current Fault‖.
5. Curve Error Shutdown
If the charger output becomes uncontrolled and
falls above or below the proper level for predeter-
mined period of time, the charger will shutdown.
All 4 LEDS will flashing and the display will read
―Curve Error Fault‖.
6. Overtemperature Shutdown
If the charger internal temperature exceeds a
predetermined limit, the charger will shut down.
All 4 LEDS will be flashing and the display will
read ―Overtemperature‖.
7. Didt Shutdown
After the 80% charged point, if the output current
begins to rise for more than a predetermined time
period, the charger will be shutdown. All 4 LEDS
will be flashing and the display will read ―Didt
Fault‖.
8. Low Voltage Shutdown
If a battery on charge does not reach a minimum
on charge voltage in a predetermined period of
time, the charger will be shutdown. All 4 LEDS will
be flashing and the display will read ―Low Voltage
Fault‖.
9. High Amp Hour Returned Shutdown
If the cycle amp hours returned exceed the BID AH
setting or charger maximum AH rating for a prede-
termined amount, the charger will shutdown. All 4
LEDS will be flashing and the display will read
―High Amp Hour Fault‖.
10. Phase Error Shutdown
If the charger control detects a problem with the
unit’s input power, the charger will shutdown.
All 4 LEDS will be flashing and the display will read
―Phase Error‖.
193111-095
OPERATION
September 30, 2011 6-3
