37. FIX. BAT. TEMP.
The battery temperature used for charger output
voltage compensation, if the charger does not
detect a Prestolite BID module (032 to 132°F).
77° = Factory Setting
CAUTION: Do Not Exceed the Battery
Manufacturer’s Maximum allowed Battery
temperature.
38. BATTERY TYPE
The battery type the charger uses to select the
proper output voltage and current characteristic, if
the charger does not detect a Prestolite BID.
0 = FLD Standard flooded lead acid industrial
type battery curve. Factory setting
1 = CTM. Custom Curve. Uses the voltage and
current values programmed in the
STRT. A/100A.H., FIN. A/100A.H., GAS. V/C,
and LID. V/C.
2 = S.L.A. Sealed Lead Acid battery curve
3 = S.L.R. A charge curve that meets the
requirements of some AGM (Absorbed Glass
Mat) Type Lead Acid Batteries
4 = D.S.G. Sealed Lead Acid battery charge curve
that meets requirements of the EPM ―DEKA‖
Sealed Lead Acid battery.
5 = S.L.E. Sealed Lead Acid battery curve
6 = D.A.G. Sealed Lead Acid battery curve
7 = C.D.R. Sealed Lead Acid battery curve
Use the up or down arrow to select the proper
setting.
NOTE: Functions 39 through 42 apply only to the
custom curve and cannot be changed unless the
custom curve has been selected in Function 38.
39. START AMPS/100
The custom output curve start current setting
(10.0 to 16.3 amps per 100 ampere-hours).
Factory setting = 16.3
40. FINISH AMPS/100
The custom output curve finish current setting
(0.0 to 7.9 amps per 100 ampere-hours).
Factory Setting = 4.5
NOTE: For Functions 41 and 42, only information
to the right of the decimal point can be entered.
41. GASSING V/C.
The custom output curve gassing voltage level
setting (2.00 to 2.99 volts/cell).
Factory setting = 2.40
42. LID. V/C.
The custom output curve lid voltage setting
(2.00 to 2.99 volts/cell).
Factory setting = 2.70
43. CHARGER I.D.
The battery charger identification number.
Factory setting = 0000
44. REFRESH DELAY
The number of hours before the charger automati-
cally starts and refresh charges a battery that has
not been disconnected (8 to 99 hours).
Factory setting = 72 hours.
45. DVDT DISABLE
Disables the automatic DV/DT charge termination
feature and enables Voltage Time charge termina-
tion.
OFF (DV/DT mode) factory setting
ON (VT mode)
Use the up or down arrow to select the proper
setting.
46. PRESENT MONTH
The current month (1 to 12).
47. PRESENT DATE
The current day of the month (1 to 31).
48. PRESENT YEAR
The current year (00 to 99).
49. MULTICELL MODE
Enables the automatic cell selection mode of opera-
tion for the charger. When turned off the charger
operates at the Fixed Cell Size (see FIXED CELL
SIZE).
OFF
ON Factory Setting
Use the up or down arrow to select the proper
setting.
50. COOL DOWN HOURS
The number of hours cool down from the end of
charge until charge complete is indicated by the
charger (0 to 8).
0 = factory setting.
Use the up or down arrow to select the proper
setting.
193111-095
PROGRAMMING YOUR EC2000 CONTROL
September 30, 2011 8-3
