Ametek ECLIPSE II User Manual

SYMPTOM PROBABLE CAUSES
ACTION
STEPS
Battery Has Low S.G.s
(1) Reading Not Temperature Corrected
(2) Bad Battery
(3) Bad Equalize Schedule
(4) Charge Curve Incorrect
(5) Rates Set Incorrectly
(6) Fixed Temperature Set Incorrectly
(7) Too Cold
(8) Bad BID
(9) Not Enough Charging Time
31
32
33
25
26
27
34
28
30
Battery Doesn’t Last Full
Shift
(1) Faulty > Lift Interrupt
(2) Manual Disconnect
(3) A.H. Required > Battery Nameplate
(4) Battery Not Providing Nameplate Rating
(5) Equalize Schedule
(6) Charge Curve Incorrect
(7) Rates Set Incorrectly
(8) Fixed Temperature Set Incorrectly
(9) Bad BID
(10) Charger Too Small For Battery
(11) Not Enough Charging Time
20
21
22
23
24
25
26
27
28
29
30
Battery Water Usage Is Too
High
(1) Rates Set Incorrectly
(2) Fixed Temperature Set Incorrectly
(3) Charge Curve Incorrect
(4) Equalize Schedule
(5) Control Set For Cell Forming
(6) Control On Voltage/Time
(7) Bad BID
26
27
25
24
35
36
28
Low Number Of A.H.s
Returned To Battery
(1) Faulty Lift Interrupt
(2) Battery Not Fully Discharged
(3) Manual Disconnect
(4) Rates Set Incorrectly
(5) Fixed Temperature Set Incorrectly
(6) Charge Curve Incorrect
(7) Battery Not Providing Nameplate Rating
(8) Bad Control Board
(9) Bad BID
(10) Charger Fans Not Operating
20
38
21
26
27
25
23
4
28
18
9-2 September 30, 2011
193111-095
TROUBLESHOOTING
