193111-095
EC2000 CONTROL FEATURES
EC2000 Charge Archive Function
The archive function allows up to 20 items of charge
cycle information to be retrieved and displayed. The
last 512 charge cycles are stored, with the most
recent cycle labeled #1 and earlier cycles labeled in
ascending order.
The most recent charger cycle data is moved to the
#1 archive location when the next battery to be
charged is connected to the charger. At this time the
all previous archive cycle data is shifted to the next
highest archive location (1 to 2, 2 to 3, etc.).
The following key sequence is used to access
charge cycle archive data:
Keys Display
PROGRAM/REVIEW Enter 1-REV 2-PROG
Function 3-MAH 4-ARCH
4 Enter Arch Func # 001
01-512/00 to Download
Key in the charge cycle number and press enter.
The charge cycle data will automatically scroll
through the display along with the charge cycle
number. The 20 archive data items are described in
detail below (see Figure 7-2).
AMP HOURS RET
The total ampere-hours returned during the charge
cycle. This number includes ampere-hours delivered
to the battery during the Verify, 0-80%, 80% to End,
and Equalize portions of the charge cycle.
CHARGE TIME
The total charging time of the charge cycle. This
number includes the time of the Verify, 0-80%
80% to End, and Equalize portions of the charge
cycle.
80% TO END
The time the battery was charged from the 80%
charged point until DV/DT or VT (depending on the
control setting) charge termination. This time does
not include any equalize charging time that may
have been automatically or manually selected.
BATTERY OCV
The open circuit voltage of the battery immediately
before the beginning of the charge cycle.
START AMPS
The value of the current delivered to the battery at
the start of the charge cycle.
START VOLTS
The value of the battery voltage (in volts/cell) of the
battery at the start of the charge cycle.
FINISH AMPS
The value of the charge current delivered to the
battery at the end of the charge cycle.
FINISH VOLTS
The value of the battery voltage at the end of the
charge cycle.
TERM
The reason for charge cycle termination. All
possible codes are listed below:
1-Charge Comp Normal Charge Complete
2-Low Current Low Current Error shutdown
3-Manual Stop Manual stop
4-Battery Dis Battery disconnected while
charging
5-<80 Backup 0-80% Back-up Timer Error
Shutdown.
9-Curve Error Charger Output Curve Error
Shutdown
10-Overtemperature Excessive Charge
Component Heating
11-Phase Error Unbalanced Input Line Error
Shutdown
12-Didt Rising Current/Falling Voltage
Error shutdown
13-Lvsd Low Charging Voltage Error
Shutdown
14-Ahsd Excessive AH Returned Error
Shutdown
16-Arcless The Arcless circuit is open
EQUALIZE TIME
The time of the equalize portion of the charge cycle.
Equalize can be automatically or manually selected.
START TIME
The time at the start of the charge cycle (military
format).
END TIME
The time at the end of the charge cycle. Includes
the equalize time if it was automatically or manually
selected (am/pm format).
BATTERY I.D.
The Battery I.D. number of the battery that was
charged in the charge cycle. Requires Prestolite
Battery Identification Module (BID).
BID START TEMP
The temperature of the battery sensed by the
Prestolite Battery Identification Module at the start of
the charge cycle.
7-6 September 30, 2011
