28. BLOCK END
Sets the ending time of the time of day blockout
function (0000 to 2359 military time). See START
MODE.
Factory = 01:00
29. START OVERIDE
Sets the start override function that allows the
operator to override any of the charger start modes
(i.e.; delayed start, time of day start, or time of day
blockout).
On = Factory setting
Use the up or down arrow to select the proper
setting.
30. START MODE
Selects the desired start mode for the start of the
charge cycle.
Automatic mode ―AUTO‖ factory setting
Time of day start mode ―T.O.D.S.‖
Delay start mode ―DEL.S.‖
Time of day blockout ―T.O.D.B.‖
Timer TIMER MODE
Use the up or down arrow to select the proper
setting.
31. FORMING CYCLES
Sets the number of forming cycles for a new battery
by disabling the low current shutdown and setting
VT Termination mode for the programmed number
of cycles (00 to 30).
00 = Factory Setting
Use the up or down arrow to select the proper
setting.
32. SPECIAL OPTION
Sets special option modes, see below:
OFF = factory setting
―P.T.S.‖ Push to start mode
The charger will not start until the ―ENTER‖ key is
pressed.
―F.L.O.‖ Fault lockout mode
The charger will not restart until any faults are reset
by pressing the ―ENTER‖ key and no battery is
connected.
Use the up or down arrow to select the proper
setting.
33. CYC. AMP HOURS
The ampere-hour setting of the charger during the
last charge cycle. This value cannot exceed the
maximum charger output rating. Not programma-
ble.
34. CYCLE CELLS
The cell size setting of the charger during the last
charge cycle. This value cannot exceed the maxi-
mum charger output rating. Not programmable.
35. FIXED CELL SIZE
The cell size the charger will operate at if the ―multi-
cell mode‖ is not selected and the charger does not
detect a Prestolite BID module. See ―MULTI-CELL
MODE‖.
Factory setting = nameplate rating
06 = 6 cells
09 = 9 cells
12 = 12 cells
18 = 18 cells
24 = 24 cells
36 = 36 cells only available on
40 = 40 cells 36 & 40 cell units
NOTE: Maximum setting is the charger
Nameplate rating.
36. FIXED AMP HRS.
The ampere-hour size the charger will operate at if
The charger does not detect a Prestolite BID
module (0001 to nameplate rating).
Factory Setting = nameplate rating
NOTE: Maximum setting is the charger
Nameplate rating.
8-2 September 30, 2011
193111-095
PROGRAMMING YOUR EC2000 CONTROL
WARNING: Enabling the Finish Cell
Forming feature will cause the
charger to continue to run for a
period of time if the battery has been
disconnected before Charge
Complete or pressing the Manual
Stop key. This condition will
Continue until the programmed
number of cycles have been
completed. The battery should never
be disconnected while a charge is in
progress.
