193111-095
EC2000 CONTROL FEATURES
10. EQUALIZE TIME
The time of the equalize portion of the charge cycle.
Equalize can be automatically or manually selected.
11. START TIME
The time at the start of the charge cycle (AM/PM for-
mat).
12. END TIME
The time at the end of the charge cycle. Includes the
equalize time if it was automatically or manually
selected (Military format).
13. CHARGER HEAT SINK TEMPERATURE
The last recorded temperature of the charger power
components heat sink while the charger was
charging.
14. BATTERY I.D.
The Battery I.D. number of the battery that was
charged in the charge cycle. Requires Prestolite
Battery Identification Module (BID).
15. BATTERY VOLTS
The present voltage of the battery connected to the
battery charger (volts DC).
16. CYCLE Kwh
The estimated Kilowatt Hour usage for the last
charge cycle.
17.
BID START TEMP
The temperature of the battery sensed by the
Prestolite Battery Identification Module at the start of
the charge cycle (degrees F).
18.
BID END TEMP.
The temperature of the battery sensed by the
Prestolite Battery Identification Module at the end of
the charge cycle (degrees F).
19. PRESENT TIME
The present time (AM/PM format).
20. WEEK DAY
The present day of week (SUN through SAT).
21.
EQUALIZE TYPE
The type of auto equalize selected. The types that
can be selected are listed below:
CYC. = By cycle count (see AUTO EQ.
COUNT).
D.O.W. = By the day of week (see Auto EQ.
Day).
BID = By BID count
22.
EQUALIZE CYCLES
The number of charge cycles between equalize
charges when the auto equalize function is pro-
grammed ―ON‖ and the auto equalize type is set to
―COUNT‖.
23. EQ. DAY
The day of the week that an equalize charge cycle is
performed when the auto equalize function is ―ON‖
and the auto equalize type is set to ―DAY‖.
24. AUTO EQUALIZE
Shows the auto equalize function on or off.
Auto equalize ―OFF‖
Auto equalize ―ON‖
25. T.O.D. START
Time of day start time. (AM/PM). See START MODE.
26. DELAYED START
Delayed start time interval. (00H 00M to 23H 59M).
See START MODE.
27. BLOCK START
The beginning time of the time of day blockout
function (AM/PM). See START MODE
28. BLOCK END
The ending time of the time of day blockout function.
(AM/PM). See START MODE.
29. START OVERIDE
The start override function that allows the operator to
override any of charger start modes (i.e. delayed
start, time of day start, or time of day blockout) by
pressing the ENTER key.
30. START MODE
Shows the selected start mode for the start of the
charge cycle.
AUTO = Automatic mode
T.O.D.S. = Time of day start mode
DELAYED = Delay start mode
T.O.D.B. = Time of day blockout
TIMER = Timer Mode
31. FORMING CYCLES
The number of forming cycles for a new battery by
disabling the low current shutdown, and setting VT
Termination mode for the programmed number of
cycles (00 to 30).
7-8 September 30, 2011
