List of Spare Parts – ATC-157 A/B
Pos. Number Spare Parts
(Compare exploded view section 3.6)
1 123125 I/O Power plate with RS232
2 123127 Display module with keyboard and PCB board
3a 123128 I/O Plate without sensor input A Models only
3b 123129 I/O Plate with sensor input B Models only
4 126035 Reference sensor
5 123783 Well, Complete without sensor
4+5 123785 Well, Complete with sensor
6 123787 Fan, Complete
7 123786 Power PCB, cooling device
8 123181 Main board without sensor input A Models only
9 123182 Main board with sensor input B Models only
10 123632 Grid plate for ATC-157
11 123628 Transformer ATC-140/156/157
12 60G032 Rubber foot
13 105575 Cable, 30-pol
14 105576 Cable, 34-pol
15 105577 Cable, 16-pol
16* 105580 Cable, 26-pol
16* 124978 Cable, 34-pol
17 105581 Cable, 2-pol
- 60E013 Power Entry Module 3A
- 125651 Backlight module for all ATC display
- 50-REP EPROM 3 E-prom for ATC
- 60B315 Fuse 5A (T) 6.3 x 32 mm UL
- 105786 Fuse 3AT, ø6.3 x 32mm UL
- 123690 Fuse 2.5AT,Ø6.3 x 32mm UL
- 105783 Fuse 1.6AT,ø6.3 x 32mm UL
- 123158 Fuse 1.6AT, MRT1.6
- 123185 Fuse 315mAT, MRT315
- 123187 Fuse 800mAT, MRT800
- 123789 Fuse 8A (T), 5 X 20mm
- 123160 Screw set, Complete
