List of Spare Parts – ATC-320/650 A/B
Pos. Number Spare Parts
(Compare exploded view section 3.8)
1 123126 I/O Power plate with RS232
2 123127 Display module with keyboard and PCB board
3a 123128 I/O Plate without sensor input A Models only
3b 123129 I/O Plate with sensor input B Models only
4 123131 Reference sensor
5 123133 Well, Complete without sensor (ATC-320 A/B)
5 123134 Well, Complete without sensor (ATC-650 A/B)
4+5 123138 Well, Complete with sensor (ATC-320 A/B)
4+5 123139 Well, Complete with sensor (ATC-650 A/B)
6 123136 Fan, Complete
7 123140 Power PCB, heating device
8 123181 Main board without sensor input A Models only
9 123182 Main board with sensor input B Models only
10 105465 Grid plate
11 105328 Transformer
12 60G032 Rubber foot
13 105575 Cable, 30-pol
14 105576 Cable, 34-pol
15 105577 Cable, 16-pol
16* 105580 Cable, 26-pol
16* 124978 Cable, 34-pol
17 105581 Cable, 2-pol
- 60D542 Power entry module 10A
- 125651 Backlight module for all ATC display
- 50-REP EPROM 3 E-prom for ATC
- 105101 Cable, 230 mm, 4 Wire
- 60B301 Fuse 5A (F) 5 x 20 mm IEC
- 60B302 Fuse 10A (F) 6.3 x 32 mm UL
- 123157 Fuse 500mAT, MRT500
- 123158 Fuse 1.6AT, MRT1.6
- 123185 Fuse 315mAT, MRT315
- 123187 Fuse 800mAT, MRT800
- 123160 Screw set, Complete
