User GuideLSPHD Linescanner Head
2.4.3 LSPHD 1 & 2 Target size table The nominal Target Size (TS)isgivenby: TS = TD / FoV Where‘FoV’istheinstrument’sFieldofView • LSPHD 10, LSPHD 11, LSPHD21&LSPHD 22 FoV=500:1 • LSPHD20     FoV=300:1
TD SW TP
LSPHD 10, LSPHD 11, LSPHD 21 & LSPHD 22
Target Size
LSPHD 20-TargetSize
Target Distance Scan Width Target Path 0° Scan angle ±40°(xaxis) ±40°(yaxis) 0° Scan angle ±40°(xaxis) ±40°(yaxis)
mm in mm in mm in mm in mm in mm in mm in mm in mm in
1000 39.4 1737 68.4 1305 51.4 2.0 0.08 7.8 0.31 6.0 0.24 3.3 0.13 10.0 0.39 7.7 0.30 1250 49.2 2156 84.9 1632 64.3 2.5 0.10 8.7 0.34 6.7 0.26 4.2 0.17 11.5 0.45 8.8 0.35 1500 59.1 2576 101.4 1958 77.1 3.0 0.12 9.6 0.38 7.4 0.29 5.0 0.20 13.0 0.51 10.0 0.39 1750 68.9 2996 118.0 2284 89.9 3.5 0.14 10.5 0.41 8.0 0.31 5.8 0.23 14.4 0.57 11.0 0.43 2000 78.7 3415 134.4 2611 102.8 4.0 0.16 11.4 0.45 8.7 0.34 6.7 0.26 16.0 0.63 12.2 0.48 2500 98.4 4254 167.5 3264 128.5 5.0 0.20 13.1 0.52 10.0 0.39 8.3 0.33 18.7 0.74 14.4 0.57 3000 118.1 5093 200.5 3916 154.2 6.0 0.24 14.8 0.58 11.4 0.45 10.0 0.39 21.6 0.85 16.5 0.65 3600 141.7 6100 240.2 4700 185.0 7.2 0.28 17.0 0.67 13.0 0.51 12.0 0.47 25.0 0.98 19.2 0.76 4000 157.5 6772 266.6 5222 205.6 8.0 0.31 18.3 0.72 14.0 0.55 6000 236.2 10128 398.7 7832 308.3 12.0 0.47 25.1 0.99 19.2 0.76 8000 315.0 13484 530.9 10443 410.7
Notes: 1) Theindicatedtargetsizesassumethatthefocusdistanceoftheinstrumentequalsthetargetdistance. 2) Iftheinstrumentisfocusedatadistancebetweenthe‘targetdistance’andthe‘targetpath’,thetargetsizeatthescan
angleextremeswillreduceattheexpenseofanincreaseatzerodegreesscanangle.
