AMETEK CTs NetWave
Models with AC voltage range up to 400 Vac / ±560 Vdc, based on the .3 models and added isolation
voltage range of 700Vac / 1000Vdc:
- NetWave 20.5
- NetWave 30.5
- NetWave 67.5
- NetWave 90.5
- NetWave 108.5
Special models with limited output voltage
- NetWave 30.4, based on 30.3 but output voltage limited to 354 Vac / ±500 Vdc
Module
includes
Power source
- AC /DC power source
- Frequency DC – 5 kHz
- AC output power : 22.5 kVA 30 kVA 67 kVA 90 kVA
- DC output power : 20 kW 36 kW 72 kW 110 kW
WaveGenerator
- On-Board supply simulator
- net.control software to generate wave shapes based on segments, point to point
matrix.
- Controller with internal hard disk.
Isolating transformer
- Included for potential free output. Allows connecting any output lead (positive or
negative) to GND. This is necessary for testing according to Military and Aircraft
standards
Options
Opt-3 Recovery
- Recovery module for power feed into the mains up to 100% of the rated AC and
DC power
Opt-3 Parallel
- Parallel mode will connect all three internal sources together in parallel for higher
current.
Opt-3 NWB
- Built-in measuring channels (6 Channels) for voltage and current (remote
controlled per USB interface)current (internal measurements)
For NetWave 60.x and 90.x in Parallel Mode the measuring channels are not
supported.
Opt-3 DC-EVR
- DC extended voltage range. Double DC voltage range, using two phases
simultaneously
Opt-3 MS
- Put 3 single NetWaves in multi-source configuration (parallel configuration) to
get one 3phase NetWave with enhanced combined power.
Opt-3 CS
- Put 2 single NetWaves in cascade source configuration (series connection) to
get one 1phase NetWave with enhanced combined power and double voltage.
