Possible device configuration at Opt-3 MS :
MS = Multi Source, CS – Cascade Source
20
MS
20.2
MS
20.3
MS
20
MS
20.2
MS
20.3
MS
67
MS
67.2
MS
67.3
MS
90.2
MS
90.3
MS
108.3
MS
AC Voltage (p-n) – MS
300
360
400
300
360
400
300
360
400
360
400
400
AC Voltage (p-n) (1 Phase) – CS
600
720
800
600
720
800
600
720
800
720
800
800
DC Voltage – MS
425
500
560
425
500
560
425
500
560
425
560
560
DC Voltage – CS
850
1000
1120
850
1000
1120
850
1000
1120
100
1120
1120
Output Power AC (kVA) – MS
67.5
67.5
67.5
90
90
90
201
201
201
270
270
324
Output Power AC (kVA) – CS
22.5
22.5
22.5
30
30
30
67
67
67
90
90
108
Output Power DC (kW) – MS
27
27
27
32
32
32
72
72
72
110
110
110
Output Power DC (kW) – CS
54
54
54
64
64
64
144
144
144
220
220
300
Output Current continuous (A)
78
78
78
99
99
99
225
225
225
300
300
300
Output Current sh. t. (max. 3s) (A)
141
141
141
198
198
198
300
300
300
450
450
450
Output Current repetitive peak (A)
400
400
400
500
500
500
600
600
600
1000
1000
1000
NetWave 20 with Opt-3 Parallel
3x
NetWave 20.2 with Opt-3 Parallel
3x
NetWave 20.3 with Opt-3 Parallel
3x
NetWave 30 with Opt-3 Parallel
3x
NetWave 30.2 with Opt-3 Parallel
3x
NetWave 30.3 with Opt-3 Parallel
3x
NetWave 67 with Opt-3 Parallel
3x
NetWave 67.2 with Opt-3 Parallel
3x
NetWave 67.3 with Opt-3 Parallel
3x
NetWave 90.2 with Opt-3 Parallel
3x
NetWave 90.3 with Opt-3 Parallel
3x
NetWave 108.3 with Opt-3 Parallel
3x
Opt-3 CS
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
Opt-3 Recovery
opt.
opt.
✓
opt.
opt.
opt.
opt.
✓
opt.
✓
✓
Enhanced Voltage Range at MS
not
not
not
not
not
not
not
not
not
not
not
not
Enhanced Voltage Range at CS
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
yes
It is not possible to put several MultiSource/CascadeSource-NetWave sources in parallel to increase the max. voltage or current further.
Additional a connection box is available (Connection L1, L2, L3, N, PE and for each line sense) :
CB-MS-20/30
Box with 3 sense connections, 3phase
Input/Output, 5 power cable, 3 sense cables with
connectors for connection of 3 NetWave 20 or
NetWave 30 in MultiSource
CB-MS-67
Box with 3 sense connections, 3phase
Input/Output, 5 power cable, 3 sense cables with
connectors for connection of 3 NetWave 67 in
MultiSource
CB-MS-90/108
Box with 3 sense connections, 3phase
Input/Output, 5 power cable, 3 sense cables with
connectors for connection of 3 NetWave 90 or
NetWave 108 in MultiSource
9.4. Opt-3 CascadeSource (3 phase systems)
With this option it is possible to put 2 single NetWave in cascade source configuration to get one NetWave with
enhanced combined DC power. See more information on chapter 8.5.
