Ametek NetWave 3.1 User Manual

AMETEK CTs NetWave
7.2. 3-phase NetWave
7.2.1. 3-phase NetWave 20, NetWave 30, NetWave 60, NetWave 67
AC / DC Power source
Output voltage
0V – 300 V AC (RMS)
0V - 425 V DC
Output frequency
DC – 5 kHz
Frequency accuracy,
stability
100 ppm
NetWave
20
30
60
67
Output power AC
22.5 kVA
30 kVA
60 kVA
67 kVA
Output power DC
27 kW
36 kW
72 kW
72 kW
Output current
@ 300V AC
26 A
47 A
200 A
33 A
66 A
250 A
66 A
100 A
400 A
75 A
100 A
400 A
(RMS) continuous
(RMS) short (max. 3s)
repetitive peak
Output connector
32 A
32 A
63 A
63 A
CEE con. or Terminal
Safety lab plugs (4/6mm banana)
7.2.2. 3-phase NetWave 20.1, NetWave 30.1, NetWave 60.1
AC / DC Power source
Output voltage
0V – 360 V AC (RMS)
0V - 500 V DC
Output frequency
DC – 5 kHz
Frequency accuracy,
stability
100 ppm
NetWave
20.1
30.1
60.1
Output power AC
22.5 kVA
30 kVA
60 kVA
Output power DC
27 kW
36 kW
72 kW
Output current
@ 300V AC
26 A
47 A
200 A
33 A
66 A
250 A
66 A
100 A
400 A
(RMS) continuous
(RMS) short (max. 3s)
repetitive peak
Output connector
32 A
32 A
63 A
CEE con. or Terminal
Safety lab plugs (4/6mm banana)
7.2.3. 3-phase NetWave 20.2, NetWave 30.2, NetWave 60.2, NetWave 67.2, NetWave 90.2
AC / DC Power source
Output voltage
0V – 360 V AC (RMS)
0V - 500 V DC
Output frequency
DC – 5 kHz
Frequency accuracy,
stability
100 ppm
NetWave
20.2
30.2
60.2
67.2
90.2
Output power AC
22.5 kVA
30 kVA
60 kVA
67 kVA
90 kVA
Output power DC
27 kW
36 kW
72 kW
72 kW
110 kW
Output current
@ 300V AC
26 A
47 A
200 A
33 A
66 A
250 A
66 A
100 A
400 A
75 A
100 A
400 A
100 A
150 A
500 A
(RMS) continuous
(RMS) short (max. 3s)
repetitive peak
Output connector
32 A
32 A
63 A
63 A
100 A
CEE con. or Terminal
Safety lab plugs
(4/6mm banana)
