AMETEK CTs NetWave
2. Model Overview
2.1. NetWave single phase models and extension modules
3.1
7
7.3
Number of Lines
1
1
1
Output Voltage AC (V) (p-n)
310
300
360
Output Voltage DC (V)
440
425
500
Output Power AC (kVA)
3
7.5
7.5
Output Power DC (kW)
4.25
9
9
Output Current continuous (A)
1)
10
26
26
Output Current short term (max. 3s) (A)
1)
20
47
47
Output Current repetitive peak (A)
1)
70
200
200
Bandwidth (kHz)
5
5
5
Isolated Output
•
Options
Opt-1 NWB
Measure extension board with
- 2 measuring input channels
for voltage and current (internal measurements)
IT-NetWave
Isolating transformer
Extension for potential free output. This option allows connecting
any output lead (positive or negative) to GND.
This isolation transformer is mandatory for testing according to
Military and Aircraft standards.
Three-phase isolation transformer for NetWave, input voltage
3x200 V or 3x400 V, output voltage 3x400 V, with 25HU rack.
Only used to upgrade existing NetWave originally delivered without
this option.
2.2. NetWave 3-phase Models
Basic models with new extended functions as follow:
Source AC, Simple AC & External Mode (refer to Annex 9.2 for detailed information):
- NetWave 20
- NetWave 30
- NetWave 60 (model replaced 2017, by NetWave 67)
- NetWave 67
Models with AC voltage range up to 360 Vac / ±500 Vdc for Aircraft application:
- NetWave 20.1 (model replaced 2012, by NetWave 20.2)
- NetWave 30.1 (model replaced 2012, by NetWave 30.2)
- NetWave 60.1 (model replaced 2012, by NetWave 60.2)
Models with AC voltage range up to 360 Vac / ±500 Vdc with new extended functions as follow:
Source AC, Simple AC & External Mode (refer to Annex 9.2 for detailed information):
- NetWave 20.2
- NetWave 30.2
- NetWave 60.2 (model replaced 2017, by NetWave 67.2)
- NetWave 67.2
- NetWave 90.2
Models with AC voltage range up to 400 Vac / ±560 Vdc with new extended functions as follow:
Source AC, Simple AC & External Mode (refer to Annex 9.2 for detailed information):
- NetWave 20.3
- NetWave 30.3
- NetWave 60.3 (model replaced 2017, by NetWave 67.3)
- NetWave 67.3
- NetWave 90.3
- NetWave 108.3
