Ametek NetWave 3.1 User Manual

AMETEK CTs NetWave
DUT monitoring
2 inputs, configurable
Signal output
Output Signal of internal arbitrary generator
(available only on all 3-phase NetWave models)
Source Input
Input for external or internal arbitrary signal generator
(available only on all 3-phase NetWave models)
Control
Computer
PC 104 computer
AMD Microprocessor 500 MHz
256 MB RAM
Operating system
Linux, with Real time extension
DSP Signal processor
Motorola DSP 56303
Interfaces
GPIB Address 1...30
Ethernet
USB (for Measure & Analyze NW-Board option)
USB (for memory stick and ext. hard disc) I max. 500 mA
RS232 ( input from DPA analyzer)
Frame bus (internal system bus)
Environmental Hard disk
Temperature
operating
5°C - 40°C
storage
-20°C - 60°C
gradient
20°C / hour
Humidity
10% - 90% non-condensing
Vibration
Operating
1.0G
Non-Operating
5.0G
Shock
Operating
225G ( 2ms)
Non-Operating
900G ( 1ms)
General Data
Safety design
per IEC 1010, EN 61010
Control F1: 3.15 A slow blow (5 x 20mm)
AC power F2: 25 A, 500 V >120 kA (10 x 38mm)
Input connector
CEE type or direct cable plugs
Noise (NW 30.2 operates)
60dB –A measured 1m in front of the device 1.5m above ground
Temperature
0 °C to 35 °C
Humidity
10 % to 90 %; non-condensing
Atmospheric pressure
86 kPa (860 mbar) to 106 kPa (1 060 mbar)
