A-16 | Thermox WDG-V Series Analyzers
Figure13.Calibration_AutoCalCongurationscreen.
Calibration Gas Duration
Dene how long you want each
calibration gas to ow through the
sensor before switching the gases.
The RCU automatically switches
the span and zero calibration gases
based on the calibration gas duration
times you specify.
Be sure to allow enough time for the gases to stabilize when you dene these times.
Calibration Frequency in days
Calibration Start Date
Click on the calendar or click on PC
Date/Time.
Calibration Start Time Hours:Minutes:Seconds
Auto Calibration Enabled This must be checked.
Next Calibrations Date/Time
This date and time must be later than
the Calibration Date and Time.
When you have completed this screen, click on the SET button to enter
the values.
