Ametek Thermox WDG-V

PC Congurator Software | A-15
Calibration_SetGasestoCalibrate
Figure11.Calibration_SetGasestoCalibratescreen.
This screen will come up when you first initiate a calibration so you can
select the gases to calibrate.
If O
2
is selected for calibration, it will be the first gas calibrated and
the zero gas will be calibrated next, then combustibles and methane.
If combustibles is the first gas selected for calibration, zero gas will be
calibrated first, then combustibles and methane.
Calibration_CalibrationHistory
Figure12.Calibration_CalibrationHistoryscreen.
View the calibration history for the selected gas in chart form and graphi-
cal representation.
