2.0 SPECIFICATIONS
These specifications pertain to the Model 217 WDR power supply only. For weld heads,
refer to the specification sheet of each particular model. For non-AMI supplied equipment
such as gas tanks and regulators, refer to the original manufacturer’s documentation. The
Model 217 WDR is a mobile system that is intended to be hand carried. The supporting
equipment such as weld heads, water coolers, gas regulators, remote controls and
extension cables can also be hand carried. Items such as gas tanks and welding fixtures
should be moved with appropriate equipment and safety precautions. Gas tanks should be
securely anchored to prevent toppling over.
2.1 ELECTRICAL
INPUT POWER DETAIL
The Model 217 WDR can operate on the following Single Phase Auto Adjusting AC inputs:
Input Power
Single-Phase
AC
Rated Welding
Output
Welding
Amperage
Range
Max OCV
DC (Uo)
Rated Peak
Starting
Voltage (Up)
Amperes Input
At Rated Load
Output, 50/60Hz,
Single-Phase
KVA
@
Duty
Cycle
115V/15A
100A@11.0
Volts DC, 100%
Duty Cycle*
5 – 100A
59V
11-16
15KV
12A
1.4
230V/30A
150A/12.0
Volts DC, 100%
Duty Cycle*
5 – 150A
59V
11-16
15KV
11A
2.4
*DUTY CYCLE is percentage of 10 minutes that unit can weld at rated load without overheating.
Input power must be grounded.
