AMI 217 WDR - ELECTRICAL SERVICE GUIDE; PHYSICAL DIMENSIONS

M O D E L 2 1 7 W D R
O P E R A T O R ’ S M A N U A L
7
OUPUT POWER DETAIL
Straight polarity, constant current DC regulation intended for GTAW welding only. Static
characteristic of all power supplies is flat.
 5 to 100 amperes DC using 100 to120 VAC input (15 Ampere service).
 5 to 150 amperes DC using 200 to 240 VAC input (30 Ampere service).
CIRCUIT BREAKER – ON/OFF, two pole, 30 Ampere at 250 VAC.
DUTY CYCLE – determined by the AC input voltage and the required output current. The
Model 217 WDR system has an internal thermal sensor that will limit operation should the
temperature exceed the safe operating parameters.
2.2 ELECTRICAL SERVICE GUIDE
FUNCTION
RANGE
INPUT VOLTAGE
115/230
INPUT AMPERE AT RATED OUTPUT
12A/11A
MAX RECOMMENDED STD. FUSE RATING IN AMPERES
 CIRCUIT BREAKER, TIME DELAY
 NORMAL OPERATING
15A
20A
MIN. INPUT CONDUCTOR SIZE (AWG)
14
MAX. RECOMMENDED INPUT CONDUCTOR
LENGTH IN FEET (METERS)
91 (28)
MIN. GROUNDING CONDUCTOR SIZE (AWG)
14
2.3 PHYSICAL DIMENSIONS
POWER SUPPLY HEIGHT
10.5” (267mm)
POWER SUPPLY WIDTH
22.75” (578mm)
POWER SUPPLY DEPTH
18.75” (476mm)
POWER SUPPLY WEIGHT
70 lbs (32 kg)
