Amkus iC550 - Combi Tool Specifications; Telescopic Ram Specifications

©Copyright AMKUS Rescue Systems 2016-2020 10 LAI-001 November 5, 2020 Rev06
4.4 COMBI TOOL SPECIFICATIONS
4.5 TELESCOPIC RAM SPECIFICATIONS
Part#: iS280-L (with lighted handle)
MECHANICAL SPECIFICATIONS
Dimensions: Length x Width x Height Inches (mm) 32.9 X 11.1 X 9.6 (836 X 282 X 244)
Weight (excluding battery) lb (kg) 50.0 (22.7)
Weight (ready to use) lb (kg) 52.4 (23.8)
Max Spreading Distance Inches (mm) 28.0 (711)
Max Spreader Opening (w/optional ERT tips) Inches (mm) 36.0 (914)
Highest Spreading Force (HSF) lb (kN) 12,720 (56.6)
Lowest Spreading Force (LSF) lb (kN) 6,610 (29.4)
Max Spreading Force lb (kN) 31,940 (142.1)
Highest Pulling Force (HPF) lb (kN) 9,590 (42.7)
Lowest Pulling Force (LPF) lb (kN) 4,960 (22.1)
Part#: iCT516
MECHANICAL SPECIFICATIONS
Dimensions: Length x Width x Height Inches (mm) 33.9 X 9.5 X 9.5 (861 X 241 X 241)
Weight (excluding battery) lb (kg) 48.0 (21.8)
Weight (ready to use) lb (kg) 50.3 (22.8)
Max Spreading Distance Inches (mm) 15.5 (394)
Highest Spreading Force (HSF) lb (kN) 8,920 (39.7)
Lowest Spreading Force (LSF) lb (kN) 6,650 (29.6)
Cutter Opening Inches (mm) 7.3 (185)
Cutter Rating NFPA 1936 A6/B7/C6/D7/E7
Part#: iTR230
MECHANICAL SPECIFICATIONS
Dimensions: Length x Width x Height Inches (mm) 17.8 X 7.3 X 11.4 (452 X 185 X 290)
Weight (excluding battery) lb (kg) 36.8 (16.7)
Weight (ready to use) lb (kg) 39.1 (17.7)
Length Retracted inches (mm) 11.4 (290)
Length Extended inches (mm) 22.6 (574)
Highest Spreading Force (HSF) Piston 1 LB (kN) 48,360 (215.1)
Lowest Spreading Force (LSF) Piston 2 LB (kN) 17,170 (76.4)
Extension Lengths Available inches (mm) 10, 18 and 27
(254, 457 and 686)
Max Extended Length (achieved with 27” extension) inches (mm) 49.6 (1260)
