©Copyright AMKUS Rescue Systems 2016-2020 8 LAI-001 November 5, 2020 Rev06
3.2 SAFETY MARKINGS
Figure 3.2
4.0 SPECIFICATIONS
4.1 GENERAL SPECIFICATIONS
Table 4.1
The 20V/60V MAX Battery pack changes voltage when you change tools, powering a line of powerful 60V MAX tools, 120V MAX tools,
and backwards compatible to existing 20V MAX tools and chargers. The battery pack is smart enough to know when to provide runtime
for 20V MAX tools and power in the new 60V MAX and 120V MAX tools.
Also compatible with:
DEWALT DCB1800B 1800 Watt Portable Power Station and Simultaneous Battery Charger - AMKUS ICHRG120-4
DEWALT DCB609 20V/60V MAX FLEXVOLT 9.0 Ah and DEWALT DCB612 20V/60V MAX FLEXVOLT 12 Ah BATTERY - AMKUS
IBATTFV-9 /IBATTFV-12
BATTERY SPECIFICATIONS Part# IBATTFFV-6
Model: DeWALT DCB606
AMKUS Part # IBATTFV-6
Dimensions: Length x Width x Height inches (mm) 4.9 x 3.3 x 3.6 (124 x 84 x 91)
Weight LB (kg) 2.25 (1.0)
CHARGER SPECIFICATIONS Part#: ICHRG120
Model: DeWALT 20VMAX* Fan Cooled Fast Charger DCB118
Input Power [Volts AC] 120
Output [Volts DC] 20
Charge Current [A] 8
Dimensions: Length x Width x Height inches (mm) 7.6 x 4.7 x 3.3 (193 x 120 x 84)
Charge Time (minutes) 60
OPERATING LIMITS
Operating Temperature Range: Degrees F (C) -25 TO 140 (-32 TO 60)
ELECTRIC DRIVE SPECIFICATIONS
Motor Type Brushless
Input Voltage [Volts DC] 60
Rated Input Current: Amps 9.8 / 25
HYDRAULIC SPECIFICATIONS
Fluid Type: AMKUS MV1 Hydraulic Fluid (Part#) KF0007
Maximum Operating Pressure PSI (bar) 10,150 (700)
OPENCLOSE
KEL 10-008
SERIAL NO: K123456
DATE OF MFG: 04/2018
MODEL: AMK—IC550
SYSTEM PRESSURE:
10,150 PSI (700 BAR)
FLUID TYPE: AMKUS MV0
60VDC Imin 9.8, Imax 28
4201 Montdale Dr., Valparaiso, IN 46383-4098
800-592-6587 • 219-548-4000
UNDERSTAND MANUAL BEFORE USE.
OPERATING AMKUS RESCUE SYSTEMS
WITHOUT UNDERSTANDING THE MANUAL,
RECEIVING PROPER TRAINING, AND
USING APPROPRIATE PERSONAL
PROTECTION EQUIPMENT IS A MISUSE OF
AMKUS EQUIPMENT. OBTAIN SAFETY
INFORMATION AT WWW.AMKUS.COM
DANGER
