AML Oceanographic AML-3 - Communicating with the Instrument

use the included USB Wall Charger
for charging the instrument.
use the included USB Wall Charger
for charging the instrument.
Temperature
-20 to +45°C (Operation)
-20 to +60°C (Storage)
-20 to +45°C (Operation)
-20 to +60°C (Storage)
Dimensions
AML-3:
Diameter: 7.6 cm / 3.0 in
Length:
Short Cage: 33.4 cm /
13.15 in (SVP set up)
Medium Cage: 39.8 cm /
15.66 in (CTD set up)
Long Cage: 46.4 cm / 18.26
in (UV Protected)
Weight*:
1.36 kg / 3.00 lb (air)
.69 kg / 1.52 lb (water)
AML-6:
Diameter: 10.0 cm / 3.90 in
Length: 60.0 cm / 23.6 in
Weight**:
4.00 kg / 8.80 lb (air)
2.00 kg / 4.40 lb (water)
AML-3:
Diameter: 7.6 cm / 3.0 in
Length:
Short Cage: 33.4 cm / 13.15
in (SVP set up)
Medium Cage: 39.8 cm /
15.66 in (CTD set up)
Long Cage: 46.4 cm / 18.26
in (UV Protected)
Weight*:
2.5 kg / 5.6 lb (air)
1.9 kg / 4.1 lb (water)
AML-6:
Diameter: 10.0 cm / 3.90 in
Length: 60.0 cm / 23.6 in
Weight**:
5.80 kg / 12.80 lb (air)
3.80 kg / 8.40 lb (water)
* With a medium cage and no sensors, deployed weights will vary
** With no installed sensors, deployment weight will vary.
1.2 Communicating with the Instrument
The preferred method of communication (setup, downloading data, etc.) is through the use of
WiFi (500m only, use USB-C for a 6000m rated instrument). By default, the instrument
automatically sets up a WiFi hotspot upon power up, allowing WiFi-enabled computers, laptops,
and tablets to directly connect.
The 500m versions of AML LGRs come with an accessory USB-WiFi dongle. Use of the dongle
is not required (any WiFi adapter will connect to the instrument) but it does provide a convenient
method for allowing a compatible PC to host two WiFi connections - the on-board WiFi adapter
remains connected with the local network, and the USB adapter connects directly to the
instrument. AML’s software, Sailfish, allows the user to selectively use available WiFi adapters
to connect to the instrument.
AML Oceanographic Ltd. 9 / 43
