3. 4
WAN CELLULAR
3G/4G Cellular Settings
In the example, the FATBOX G3
would send a PING to Google's
public DNS every 15 seconds.
If 4 consecutive PING failures
occur, the FATBOX G3 would
attempt to re-establish a
connection.
If it fails to establish a
connection after 5 tries, the G3
will reboot itself.
8.8.8.8
+61430XXXXXX
15
4
reboot
Advanced Settings
SMS Reboot Settings
Enable Reboot on Ping Failure
Enable SMS Reboot
Controller 1
Primary WAN Interface
PPP Fail Reboot
After SMS Reboot
PING Remote Host
PING Interval
PING Retries
Controller 2
Reboot Command
Before SMS Reboot
This is the time taken before each ping
would be sent
This is the number of times it retries before
the FATBOX G3 would attempt to
re-establish a connection
“Cellular” : Operates internet connectivity
through a cellular network
“Ethernet” : Operates internet connectivity
through ETH1 with an existing network
connection (You will also be required to set
the ‘ETH1 IP Address’ and ‘ETH1 Gateway’
in
the ‘LAN Ethernet’ page to do this)
Enter the IP address/ website which you
would ping
This enables the FATBOX to reboot upon
the failure to PING your selected IP address
UPDATE and restart FATBOX
Enable/disable the SMS reboot function
Input an authorised number as main controller
Click to enable PPP Fail Reboot
Input an authorised number as controller 2
Select your command to reboot the G3
Select your conrmation message from the G3
before it carries out the reboot.
Select your conrmation message from the G3
after it carries out the reboot.
UPDATE
Disabled
Disabled
Cellular
Disabled
PPP Keep Alive
Note: Please disable 'Signal LEDs' in System Management
Send SMS to active controller before reboot
Send SMS to main controller after reboot
