AMSAFE SEATBELT AIRBAG SYSTEM
INSTALLATION, HANDLING AND SHIPPING INSTRUCTIONS E510629
SYSTEM DESCRIPTION AND OPERATION
: 02-Aug-2013
Page 3
Figure 3: Representative Dual Inflator AmSafe Seatbelt Airbag System
Figure 4: Representative Structure Mounted Airbag System
Structure Mounted Airbag
Assembly Representation
EMA
Diagnostic
Connector
Inflator
Interfac
e cable
EMA
Cable Interface
Assembl
y
Lift-Latch Buckle
Assembly
Part of Inflatable
Inflator Fitting
(Axial)
Airbag Belt – 2-Point
Part of Inflatable Lap
Belt Assembly
Diagnostic
Connector
Dual Inflators
