AMSAFE SEATBELT AIRBAG SYSTEM
INSTALLATION, HANDLING AND SHIPPING INSTRUCTIONS E510629
REPAIR
02-Aug-2013
Page 2001
REPAIR
1. AMSAFE SEATBELT AIRBAG SYSTEM REPAIR
A. Scope of the Job
(1) The primary repair of the AmSafe Seatbelt Airbag System is the removal and replacement of
defective subassemblies. The SDT battery will need to be replaced occasionally.
B. Limitation of the Job
(1) Disassemble the AmSafe Seatbelt Airbag System only to the level necessary to replace the
defective subassembly as determined during the diagnostic check detailed in the “TESTING
AND FAULT ISOLATION” section of this manual, starting on Page 1001. When new
subassemblies are necessary, refer to the parts list for the correct part numbers, quantities,
and attaching hardware.
WARNING:
THE INFLATOR IS A STORED GAS/ENERGETIC MATERIAL DEVICE. SEVERE
PERSONAL INJURY OR BODILY HARM MAY BE CAUSED BY MISUSE AND/OR
TAMPERING. DO NOT MISHANDLE THE PRODUCT IN ANY WAY. NEVER
ATTEMPT TO OPEN THE INFLATOR TO SERVICE THE GAS GENERATION
SYSTEM. NEVER
APPLY ELECTRICAL CURRENT TO THE ELECTRONICS
CONNECTION. DO NOT TAMPER WITH THE INFLATOR IN ANY WAY.
CAUTION:
THE AMSAFE SEATBELT AIRBAG SYSTEM MAY NOT BE DISASSEMBLED OR
REPAIRED BEYOND THE LEVEL INDICATED IN WITHIN THE SCOPE OF THIS
MANUAL. SCOPE INCLUDES REPAIRS INDICATED IN ALL LISTED, ACTIVE
SERVICE BULLETINS AND LETTERS. FURTHER DISASSEMBLY OR REPAIR
OF THIS SYSTEM MAY ONLY BE CARRIED OUT BY AMSAFE. AMSAFE IS NOT
RESPONSIBLE FOR DAMAGE OR MALFUNCTIONS RESULTING FROM ANY
UNAUTHORIZED ATTEMPT TO REPAIR OR DISASSEMBLE THE RESTRAINT
SYSTEM.
C. Equipment and Materials for the Job
(1) The equipment and materials required for installation and removal of the AmSafe Seatbelt
Airbag System are specified in the associated portion of this manual.
D. Procedures
(1) Procedures for identifying and diagnosing system failures are specified in the “TESTING AND
FAULT ISOLATION” section of this manual starting Section 1000.
(2) Procedures for replacement are specified in the “REMOVAL AND INSTALLATION
PROCEDURE” section of this manual starting in Section 3000.
(3) To replace the SDT battery, locate and remove battery compartment cover. Remove the
battery and replace with a new, standard 9-volt battery. Replace cover.
