AMSAFE V23 - Equipment and Materials Required

AMSAFE SEATBELT AIRBAG SYSTEM
INSTALLATION, HANDLING AND SHIPPING INSTRUCTIONS E510629
REMOVAL REPLACEMENT AND INSTALLATION PROCEDURES
02-Aug-2013
Page 3003
C. Equipment and Materials Required
(1) The following items are required to remove the AmSafe Seatbelt Airbag System.
Table 3: Removal Equipment and Materials
Qty Description Part Numbe
r
1 Repairman Tool Kit Standard Issue
2 Safety Glasses Standard Issue
1 Screwdriver Bit Set, Hex Drive Standard Issue
1 Torque Wrench, In. Lb. Type Standard Issue
As Required Loctite 242 or equivalent Loctite Corporation
(2) Use the following tables to identify the appropriate torque value, tool, and tool size to use for
attaching hardware throughout the removal and replacement process. Associate the
appropriate tool/torque on Table 4 by callouts listed throughout instructions.
Table 4: Torque Values and Tool Sizes
D. AmSafe Seatbelt Airbag System Removal
(1) Enabling Switch Systems: Access yellow connectors that connect the Inflatable Lap Belt
Assembly or Buckle Assembly to Cable Interface Assembly connector(s) (Figure 12) and
disconnect by sliding the red locking tab backwards (Figure 13) to the unlocked position.
Depress the yellow tab and pull apart both connector halves.
(2) Remove squib connector from the Inflator by squeezing both sides of the connector and
gently pulling away from the Inflator (Figure 13).
Part Description Tool and Size Part Number
Torque - In. Lbs.
(above run-on
torque)
Electronic Module Assembly
(EMA)
Torque Wrench, In. Lb type
508358-401 thru -411
508358-413 thru -423
508224-401 thru -411
508224-413 thru -423
30 +/- 2
6 +/- 2
30 +/- 2
6 +/-2
Connection Tool and Size Torque - In. Lbs.
Inflator to Inflator Fitting Torque Wrench, In. Lb type 60 +/-10
Inflatable Lap Belt Assembly to
Inflator Fitting
Torque Wrench, In. Lb type 120 +/-10
