AMSAFE V23 - F. Installation of Seats Equipped with AmSafe Seatbelt Airbag System; G. Removal of Seats Equipped with AmSafe Seatbelt Airbag System

AMSAFE SEATBELT AIRBAG SYSTEM
INSTALLATION, HANDLING AND SHIPPING INSTRUCTIONS E510629
REMOVAL REPLACEMENT AND INSTALLATION PROCEDURES
02-Aug-2013
Page 3008
F. Installation of Seats
Equipped with AmSafe Seatbelt Airbag System
WARNING
: IF INSTALLED, DO NOT REMOVE THE SAFETY TIE FROM THE AIRBAG
TONGUE UNTIL THE SEAT IS INSTALLED IN THE AIRCRAFT.
WARNING
: DO NOT CARRY SEAT BY THE AMSAFE SEATBELT AIRBAG SYSTEM. THIS
MAY CAUSE DAMAGE TO THE SYSTEM THAT MAY REQUIRE REPLACEMENT
OF COMPONENTS.
(1) Install seats in aircraft per seat OEM and aircraft OEM instructions.
(2) Non-Enabling Switch Systems: Connect EMA and Cable Interface Assembly on seats with
Non-Enabling Switch System.
(3) Remove any protective coverings that may be present on the Airbag Belt and Buckle Belt.
(4) Inspect the Airbag System to ensure all connections are made and the EMA is securely
mounted to the seat frame.
(5) Perform a system diagnostics test verify that the AmSafe Seatbelt Airbag System is
operational. Follow procedures shown in the Testing and Fault Isolation Section of this
document (Section 1000). The AmSafe Seatbelt Airbag System equipped seat is now ready
for use.
G. Removal of Seats
Equipped with AmSafe Seatbelt Airbag System
NOTE
: IF REMOVAL OF AMSAFE SEATBELT AIRBAG EQUIPPED SEAT IS REQUIRED,
BE SURE TO FIRST COVER THE AIRBAG BELT TO KEEP FROM ACCIDENTAL
DAMAGE TO THE AIRBAG BELT COVER.
(1) Safe the system by installing a Safety Tie (or equivalent type tie wrap) through the airbag
belt’s tongue to prevent buckling of the two seatbelt halves.
(2) The BUCKLE HALF OF THE SEATBELT AIRBAG SYSTEM SHOULD BE FOLDED OVER
ON ITSELF, COVERED AND SECURED PRIOR TO REMOVAL OF THE SEAT. This will
protect the buckle from any damage and ensure the AmSafe Seatbelt Airbag System cannot
be accidentally enabled by the buckling of the Inflatable Lap Belt Assembly or proximity to the
belt tongue.
